SVM

Forward

The loss of each class is calculated as below:

\[ \begin{equation} L = \sum_{j}^{j \neq y_i} \max(0, S_j - S_{y_i} + \delta) \end{equation} \]

An example will better illustrate the process.

Suppose there are 3 classes and each score is \(s_1\), \(s_2\), \(s_3\) and this image belongs to label \(1\), i.e. \(y_i = 1\). Also, \(\delta\) is set to 1 as default.

\[ L = max(s_2 - s_1 + 1, 0) + max(s_3 - s_1 + 1, 0) \]

Notice that we didn't take \(max(s_1 - s_1 + 1, 0)\) since \(s_1\) is our target label.

SVM Nature

SVM essentially wants the loss of correct class to be larger than the incorrect classes by at least \(\delta\). If this is not the case, we will accumulate loss.

Backward

When it comes to calculating the gradients, we need to write down every single equation and with the help of chain rule, we connect each separate part together.

\[ \begin{align} L &= \dfrac{1}{N} \sum_{i=1}^{N} L_i \\ &= \dfrac{1}{N} \sum_{i=1}^{N} (\sum_{j}^{j \neq y_i} \max(0, s_j - s_{y_i} + 1)) \end{align} \]

To calculate the gradients:

\[ \begin{align} \dfrac{\partial L}{\partial W} &= \dfrac{1}{N} \sum_{i=1}^{N} \dfrac{\partial L_i}{\partial W} \\ \end{align} \]

Abstract it:

\[ \begin{align} \dfrac{\partial L_i}{\partial W} &= \sum_{k=1}^{C} \dfrac{\partial L_i}{\partial s_k} \times \dfrac{\partial s_k}{\partial W} \end{align} \]

Furthermore:

\[ \begin{align} \dfrac{\partial L_i}{\partial s_k} &= \dfrac{\partial \sum_{j}^{j \neq y_i} \max(0, s_j - s_{y_i} + 1)}{\partial s_k} \\ &= \sum_{j}^{j \neq y_i} \dfrac{\partial \max(0, s_j - s_{y_i} + 1)}{\partial s_k} \\ &= \begin{cases} 0 & \text{if } j = y_i \text{ or } k \neq j \text{ or } s_j - s_{y_i} + 1 \leq 0 \\ 1 & \text{otherwise } \end{cases} \end{align} \]

in which \(s_k\) is short for \(s_k - s_{y_i} + 1\). This may seem a little unintuitive. Just treat \(s_j - s_{y_i} + 1\) as a whole and the entire expression will make a lot more sense.

Furthermore:

\[ \begin{align} \dfrac{\partial s_k}{\partial W} &= \begin{bmatrix} \dfrac{\partial s_k}{\partial W_{11}} & \dfrac{\partial s_k}{\partial W_{12}} & \dots & \dfrac{\partial s_k}{\partial W_{1C}} \\ \vdots & \vdots & \ddots & \vdots \\ \dfrac{\partial s_k}{\partial W_{D1}} & \dfrac{\partial s_k}{\partial W_{D2}} & \dots & \dfrac{\partial s_k}{\partial W_{DC}} \end{bmatrix} \end{align} \]

At each matrix slot, the value of \(\dfrac{\partial s_k}{\partial W_{mn}}\) depends on whether \(s_k\) is 0.

If it is, the derivative is 0 for sure.

If not,

\[ \begin{align} s_k &= s_k - s_{y_i} + 1 \\ &= \mathbf{X} \cdot \mathbf{W_k} - \mathbf{X} \cdot \mathbf{W_{y_i}} + 1 \end{align} \]

Note, the \(W_k\) here means the kth column of the weight matrix.

Thus, (suppose \(s_k\) is not 0), \(\dfrac{\partial s_k}{\partial W_{mn}} = X_n\)

Code

The theory is a mind-boggling. Let's walk through the code along with the theories we've just cracked.

Naive Approach

def svm_loss_naive(W, X, y, reg):
    """
    Structured SVM loss function, naive implementation (with loops).

    Inputs have dimension D, there are C classes, and we operate on minibatches
    of N examples.

    Inputs:
    - W: A numpy array of shape (D, C) containing weights.
    - X: A numpy array of shape (N, D) containing a minibatch of data.
    - y: A numpy array of shape (N,) containing training labels; y[i] = c means
      that X[i] has label c, where 0 <= c < C.
    - reg: (float) regularization strength

    Returns a tuple of:
    - loss as single float
    - gradient with respect to weights W; an array of same shape as W
    """
    dW = np.zeros(W.shape)  # initialize the gradient as zero

    # compute the loss and the gradient
    num_classes = W.shape[1]
    num_train = X.shape[0]
    loss = 0.0

    for i in range(num_train):
        scores = X[i].dot(W)
        correct_class_score = scores[y[i]]
        for j in range(num_classes):
            if j == y[i]:
                continue
            margin = scores[j] - correct_class_score + 1  # note delta = 1
            if margin > 0:
                dW[:, j] += X[i]
                dW[:, y[i]] -= X[i]
                loss += margin

    # Right now the loss is a sum over all training examples, but we want it
    # to be an average instead so we divide by num_train.
    loss /= num_train

    # Add regularization to the loss.
    loss += reg * np.sum(W * W)

    #############################################################################
    # TODO:                                                                     #
    # Compute the gradient of the loss function and store it dW.                #
    # Rather than first computing the loss and then computing the derivative,   #
    # it may be simpler to compute the derivative at the same time that the     #
    # loss is being computed. As a result, you may need to modify some of the   #
    # code above to compute the gradient.                                       #
    #############################################################################
    # *****START OF YOUR CODE (DO NOT DELETE/MODIFY THIS LINE)*****

    # Average the gradient
    dW /= num_train
    dW += 2 * reg * W

    # *****END OF YOUR CODE (DO NOT DELETE/MODIFY THIS LINE)*****

    return loss, dW

Vectorized Approach

def svm_loss_vectorized(W, X, y, reg):
    """
    Structured SVM loss function, vectorized implementation.

    Inputs and outputs are the same as svm_loss_naive.
    """
    loss = 0.0
    dW = np.zeros(W.shape)  # initialize the gradient as zero

    #############################################################################
    # TODO:                                                                     #
    # Implement a vectorized version of the structured SVM loss, storing the    #
    # result in loss.                                                           #
    #############################################################################
    # *****START OF YOUR CODE (DO NOT DELETE/MODIFY THIS LINE)*****

    scores = np.dot(X, W)
    scores = np.maximum(0, scores - scores[range(len(scores)), y].reshape(-1, 1) + 1)
    scores[range(len(scores)), y] = 0

    loss = np.sum(scores) / X.shape[0]
    loss += reg * np.sum(W * W)

    # *****END OF YOUR CODE (DO NOT DELETE/MODIFY THIS LINE)*****

    #############################################################################
    # TODO:                                                                     #
    # Implement a vectorized version of the gradient for the structured SVM     #
    # loss, storing the result in dW.                                           #
    #                                                                           #
    # Hint: Instead of computing the gradient from scratch, it may be easier    #
    # to reuse some of the intermediate values that you used to compute the     #
    # loss.                                                                     #
    #############################################################################
    # *****START OF YOUR CODE (DO NOT DELETE/MODIFY THIS LINE)*****

    dvalues = (scores > 0).astype(float)
    dvalues[range(len(dvalues)), y] -= np.sum(dvalues, axis=1)
    dW = np.dot(X.T, dvalues) / X.shape[0]

    dW += 2 * reg * W

    # *****END OF YOUR CODE (DO NOT DELETE/MODIFY THIS LINE)*****

    return loss, dW
